Sewage treatment plants for ships

Sewage treatment plants (STPs) from Wärtsilä are the most cost-effective and safe answer for every ship or offshore platform to dispose of wastewater at sea. No tempering with the quality of our oceans.

Wärtsilä sewage treatment units - also known as 'Hamworthy Sewage Treatment Plants' - are certified to meet IMO MEPC 227(64) guidelines. These have been in place for all new-build ships from 1 January 2016 onward.

Each Wärtsilä/Hamworthy sewage treatment unit has been optimised to process all onboard black and grey wastewater streams. The plants are compatible with both conventional gravity and vacuum fed collection systems. On top of that, each STP is fully automatic, allowing for unattended operation. This greatly reduces maintenance requirements and lower long-term operating costs.

Finally, Wärtsilä sewage treatment plants for ships are compact and modular in design, suitable for between-deck installations and adaptable to customer new-build specifications.

    KEY BENEFITS

    Benefits of Wärtsilä sewage treatment plants

    • Cost-effective, environmental friendly & safe answer for every ship to dispose of waste water at sea
    • Proven effluent quality: clean and safe effluent, suitable for discharging overboard
    • Low operational costs with:
      • minimal maintenance & spare parts required
      • minimal human intervention during operation
    • Simple & robust construction
    • Compatible with gravity & vacuum collection systems
    • Collecting tank integral part of STP

    FEATURES

    Main features

    • IMO 227(64) & MED certified
    • Single power supply input point
    • Solids handling centrifugal discharge pump
    • Chemical disinfection and de-chlorination
    • Automatic control
    • Compact design

    MODELS

    STC 13 line

    System IMO certified
    (litres/day)
    Dimensions
    (LxWxH in mm)
    Weight full
    (kg)
    STC-01-13 1740 1890 1400 1181 1550
    STC-02-13 3120 2518 1863 1336 3030
    STC-03-13 4660 2622 1863 1681 3959
    STC-04-13 6010 2722 2080 1821 5027
    STC-06-13 9360 3072 2280 1971 7367

    STC 14 line

    System IMO certified
    (litres/day)
    Dimensions
    (LxWxH in mm)
    Weight full
    (kg)
    STC-08-14 11840 3000 2670 2000 9294
    STC-10-14 15810 3400 2750 2000 11314
    STC-13-14 20830 4400 2750 2000 15036
    STC-15-14 25704 3700 3215 2300 17836
    STC-20-14 33974 4620 3215 2300 22422
    STC-25-14 40778 4620 3490 2500 27446
    STC-30-14 47422 5012 3470 2700 30898
    STC-40-14 64150 6012 3915 2680 43614
    STC-50-14 80182 7000 4145 2900 55526
    STC-60-14 100800 7000 4180 3500 69754

    SCOPE OF SUPPLY

    As standard

    • Main tank
    • Air compressor
    • Discharge pump
    • Electrical control panel
    • Chlorination & dechlorination systems

    Optional

    • Fitted vacuum sewage collection equipment
    • Conditioning water flow meter
    • Standby compressor (mounted)
    • Standby discharge pump (mounted)
    • Maceration
    • Separate sewage feed system
    • Retrofit options available to aid installation

    References

    • Asian Hercules II

      “Asian Hercules II”, a 3,200 MT Floating Sheerleg Crane vessel, has 4 main hoisting winches, each capable of hoisting speeds 2m/min with a full load. Delivered in 1997, the vessel has an accommodation facility for 34 persons.

      Asian Hercules II
    • Twister

      The AQUARIUS® UV Ballast Water Management System (BWMS) was installed onboard the Twister, a Chemgas BV owned LPG carrier.

      For retrofit applications and upgrades, where space availability can be a determining factor, the modular configuration of Wärtsilä’s AQUARIUS® range was a particular advantage and the entire installation process took just 3 weeks.

      Twister
    • Leonidas

      Delivered in 2009, the 318,000 dwt Leonidas features a machinery installation incorporating a Wärtsilä 7RT-flex82T. The vessel is also equipped with the Super Trident Sewage Treatment Plant ST2A, certified to meet IMO MEPC 159(55) guidelines.

      Leonidas
    • HMS Daring

      The HMS Daring, commissioned in 2009, is the first of six vessels of the new Type 45 class. Each Type 45 Destroyer has an IEP (Integrated Electric Propulsion) system consisting of two gas turbine alternators and two Wärtsilä 12V200 diesel alternators. (photo courtesy of BVT). The vessel is also fitted with a MBR50N membrane bioreactor for advanced wastewater processing.

      HMS Daring Courtesy BAE Systems
