    Hamworthy sewage treatment plants (STPs)

    Hamworthy sewage treatment plants or units | certified IMO MEPC 227(64) | low maintenace

    Hamworthy sewage treatment plants (STPs) are a standard in the marine & offshore market. The Hamworthy STP is known to be the most cost-effective and safe answer for processing wastewater at sea. No tempering with our oceans' quality, operating in full compliance with IMO MEPC 227(64) and other stringent guidelines.

    Each Hamworthy sewage treatment unit is optimised for processing onboard black and grey wastewater streams. The plants are compatible with both conventional gravity and vacuum fed collection systems. They can be operated with salt and freshwater. Each STP is fully automated, allowing for unattended and flexible operation. On-board maintenance requirements are reduced and long-term operating costs are significantly lowered.

    Hamworthy sewage treatment plants are compact and modular in design, suitable for between-deck installation and adaptable to the customer's new-build specifications. Produced by Wärtsilä Water & Waste.

      KEY BENEFITS

      Benefits of Hamworthy sewage treatment plants

      • Made by the market leader, with over half a century of experience
      • Proven effluent quality: clean and safe effluent, suitable for discharging overboard
      • Low OPEX:
        • minimal maintenance & spare parts required
        • minimal human intervention during operation
        • Compatible with gravity and vacuum collection systems, sea- and freshwater
        • Highly flexible in operation thanks to automatic control system

      FEATURES

      Main features

      • IMO 227(64) & MED certified
      • Single power supply input point
      • Solids handling centrifugal discharge pump
      • Chemical disinfection and de-chlorination
      • Automatic control
      • Simple & robust construction, made from top quality components
      • Compact design with collecting tank as integral part of STP

      Models

      Hamworthy STC-13 line (small capacities)

      SystemIMO certified
      (litres/day)      		Dimensions
      (LxWxH in mm)      		Weight full
      (kg)
      STC-01-1317401890140011811550
      STC-02-1331202518186313363030
      STC-03-1346602622186316813959
      STC-04-1360102722208018215027
      STC-06-1393603072228019717367

      Hamworthy STC-14 line (large capacities)

      SystemIMO certified
      (litres/day)      		Dimensions
      (LxWxH in mm)      		Weight full
      (kg)
      STC-08-14118403000267020009294
      STC-10-141581034002750200011314
      STC-13-142083044002750200015036
      STC-15-142570437003215230017836
      STC-20-143397446203215230022422
      STC-25-144077846203490250027446
      STC-30-144742250123470270030898
      STC-40-146415060123915268043614
      STC-50-148018270004145290055526
      STC-60-1410080070004180350069754

      SCOPE OF SUPPLY

      As standard

      • Main tank
      • Air compressor
      • Discharge pump
      • Electrical control panel
      • Chlorination & dechlorination systems

      Optional

      • Fitted vacuum sewage collection equipment
      • Conditioning water flow meter
      • Standby compressor (mounted)
      • Standby discharge pump (mounted)
      • Maceration
      • Separate sewage feed system
      • Retrofit options available to aid installation

      After-sales support

      Hamworthy SPTs are fully supported throughout their lifecycle. Owners and operators can count on:

      All Hamworthy sewage treatment units are commissioned by qualified commissioning engineers.

      Automation of Wärtsilä Waste and Wastewater treatment systems
