Wärtsilä Piston upgrade with internal lubrication and APR

Setting the optimal lube-oil flow for Wärtsilä ZA40S engines equipped with an external lubrication system can be a challenging and time-consuming process that requires specialist knowledge. Incorrect lube-oil flow can lead to a risk of engine failure resulting from inadequate piston lubrication and lead to exhaust-pipe fouling in cases of too-high oil flow.

The Wärtsilä Piston upgrade for ZA40S engines with internal lubrication and APR is suitable for marine and power plant installations with an output range of 660–720 kW/cyl equipped with an external piston lubrication system. The upgrade replaces the external lubrication system with a new internal system combined with an anti-polishing ring (APR) to reduce lube-oil consumption by up to 50% as well as maintenance complexity and cost.

As well as improving lubrication of the piston surface during engine start and operation, the upgrade results in a simpler lubrication circuit, reducing labour and spare-part costs compared to an external system. Furthermore, it also reduces both lubrication costs and exhaust-pipe fouling in cases where too-high oil flow leads to lube-oil spillage. Unburnt lube oil directly contributes to particle mass (PM) emissions, while some ash components from combusted lube oil can shorten the lifetime of after-treatment devices.

    Technical info

    The internal lubrication system has been installed as standard in all Wärtsilä ZA40S engines manufactured from 1996 onwards. The system consists of a bore-cooled steel crown with combined oil spray and shaker cooling. There are three piston ring grooves and one oil scraper ring on the piston crown. The oil used to lubricate the piston and liner is directly supplied from the oil sump instead of from a dedicated tank. The oil is directly injected between the moving sliding parts, passing through the internal orifices in the connecting rod, piston crown and piston skirt.

    Installing an APR increases clearance between the piston top and liner wall and considerably reduces contact between carbon deposits and the liner wall during piston tilting.

    The upgrade comprises the following:

    • APR-ready piston assembly with internal lubrication system
    • APR-ready cylinder liner
    • Anti-polishing ring

    The upgrade process involves dismantling and reassembling the piston assembly and the cylinder liners and dismantling the external lube-oil circuit. The optimal time to perform the upgrade is during a major engine overhaul, for example at 48,000 hours.

    Benefits
    • Improved piston surface lubrication
    • Reduced wear on piston ring, piston and cylinder liner
    • Reduced consumption of lubrication oil by up to 50%
    • Simplified maintenance and monitoring
    • Reduced exhaust-pipe fouling, PM emissions, visible smoke, carbon deposits and after-treatment device clogging
    Application

    The Wärtsilä Piston upgrade for ZA40S engines with internal lubrication and APR is suitable for marine and power plant installations with an output range of 660–720 kW/cyl equipped with an external piston lubrication system. This mainly concerns Wärtsilä ZA40S engines manufactured before 1996.
